Specifications

Ricoh
Engine/General Specifications
Configuration
Console
Printing Process
4-Drum Method

Control Panel

Ricoh

10.1″ Smart Operation Panel
Color / Black & White
Color
Output Speed Copy/Print
45 ppm B&W & FC (LTR)
First Page Out Time
3.6 seconds B&W
5.4 seconds Color
Warm-Up Time
21 seconds
Resolution
600 dpi

System Memory

Ricoh

2 GB RAM/320 GB HDD Standard & 4 GB RAM/320 GB HDD Option
Maximum Copy Quantity
Up to 999 copies
Duplexing
Automatic (Standard)
Document Feeder Type
Single Pass Document Feeder (SPDF)
Original Capacity: 220 sheets
Original Size: 5.5″ x 8.5″ – 11″ x 17″ (A5-A3)
Paper Weight: Simplex: 11 – 34 lb. Bond (40 – 128 g/m2)
Duplex: 14 -34 lb. Bond (52 – 128 g/m2)
Zoom Range
25% – 400% in 1% increments

Supported Paper Sizes

1st Paper Tray: 8.5″ x 11″ (A4)
2nd Paper Tray: 5.5″ x 8.5″ – 12″ x 18″ (SRA3, A3-A6, B4-B6), Envelopes
Bypass: Up to 12″ x 18″, Envelopes
Custom Sizes: Width: 3.5″ – 12.6″ (90 – 320 mm), Length: 5.8″ – 49.6″ (148 – 1260 mm)
Supported Paper Weights
Standard Trays: 16 – 80 lb. Bond/166 lb. Index (60 – 300 g/m2)
Bypass Tray: 14 – 80 lb. Bond/166 lb. Index (52 – 300 g/m2)
Duplex Unit: 14 -68 lb. Bond/142 lb. Index (52 – 256 g/m2)
Supported Paper Types
Plain, Recycled, Special, Colored, Letterhead, Cardstock, Pre-printed, Bond, Coated, Envelope, Label, OHP, Gloss

Standard Paper Capacity

1,200 sheets (2 x 550 sheets + 100-Sheet Bypass Tray)
Maximum Paper Capacity
4,700 sheets (w/Tandem LCT + Side LCT)
Standard Output Capacity
500 sheets 8.5″ x 11″ (A4) or smaller; 250 sheets (B4) or larger
Maximum Output Capacity
3,625 sheets
Maximum Monthly Volume
50000
Power Source
120V – 127V, 60Hz
Typical Electricity Consumption (TEC)
0.512 kWh/week
TEC value is measured based on the ENERGY STAR Ver.3.0 test method.
Power Consumption
Less than 1,584 W; Sleep Mode: 0.59W
EPEAT status
Gold
Dimensions W x D x H
23.0″ x 27.0″ x 37.9″ (587 mm x 685 mm x 963 mm)
Weight
223.5 lbs/101.4 kg
Printer Specifications
Processor Speed
Intel Apollo Lake 1.6 GHz
Interfaces
Standard: Ethernet 10 base-T/100 base-TX/1000 base-T, USB Host I/F Type A, USB Device I/F Type B
Option: Wireless LAN (IEEE 802.11a/b/g/n), Additional NIC (2nd port)
Network Protocol
TCP/IP (IPv4, IPv6)
Supported Operating Systems
Windows® V7/8.1/10/Server 2008/Server 2008R2/ Server2012/ Server2012R2/Server 2016; Unix: Sun Solaris. HP-UX. SCO Open Server. RedHat Linux. IBM AIX. Mac OS X v.10.11. Or later. SAP R/3. SAP S/4. IBM iSeries AS/400-using OS/400 Host Print Transform
Device Management Utilities
Device Manager NX Series, Web Image Monitor, @Remote
Printer Languages
Standard: PCL5c, PCL6, PostScript®3™ Emulation, PDF Direct Print Emulation
Optional: Genuine Adobe® PostScript®3™, Adobe® PDF Direct Print
Font Support
Standard: PCL: 45 Roman fonts + 13 International fonts
PostScript®3™ Emulation: 80 Roman fonts + 13 International fonts
Optional: Genuine Adobe® PostScript®3™: 136 Roman fonts
Print Resolution
Up to 1200 x 1200 dpi
Mobile Printing Support
Apple AirPrint™, Mopria, Google Cloud Print, NFC, Ricoh Smart Device Connector
Security Features
DataOverwriteSecurity System (DOSS), HDD Encryption, User Codes, SNMP v3 Support, Encryption, Locked Print, User Authentication, 802.1x Wired Authentication, Quota Setting/Account Limit, Digitally Signed PDF, and more
Scanner Specifications
Scan Speed BW Full Color
120 ipm (simplex)/240 ipm (duplex)
Scanning Resolution
Up to 1200 dpi
Scan Area
11.7″ x 17″ (297 – 432 mm)
File Formats
Single Page: TIFF, JPEG, PDF, PDF/A, High Compression PDF, encryption PDF, OCR*
Multi Page: TIFF, PDF (Default), PDF/A, High Compression PDF, encryption PDF, OCR*
Scan Modes
E-mail, Folder, USB, SD Card

*Requires optional OCR Unit Type M13
Document Server Specifications
Maximum Stored Documents
3000
Maximum Pages/Document
2000
Maximum Page Capacity
9000
Max Number of Folders
200
Fax Specifications
Type
ITU-T (CCITT) G3
Circuit
PSTN, PBX
Fax Resolution
Standard: 8 x 3.85 line/mm, 200 x 100 dpi
Optional: 16 x 15.4 line/mm, 400 x 400 dpi
Compression Method
MH, MR, MMR, JBIG
Scanning Speed
81 spm (A4/LT LEF Image Rotation)
Modem Speed
33.6 Kbps
Transmission Speed
2 seconds (200 x 100 dpi, JBIG, ITUT #1 chart TTI off, memory transmission)
Memory
Standard: 4 MB (approx. 320 pages)
Optional: 60 MB (approx. 4,800 pages) with optional SAF memory
Max Auto Dials
2,000 Quick/Speed Dial numbers
Group Dials
100 Group Dial numbers
